13.3″ Capacitive Touch Monitor

faytech’s Capacitive Touch Monitors have a modern sleek look with its flat edge to edge glass IP65 water- and dust proof front panels. This device has capacitive 10-finger multitouch, glass front reaching MosH 7, the glass surface is anti-glare treated (chemical etching) and a wide variety of connectors. All the monitors have VESA 100 screw patterns on the back. This solution consists of front kit and back kit, ensuring your required configuration is easily customizable.

This device has an optically bonded touch panel, which will improve the stability, reduce the reflection, increase the viewing angle, and enhance the perceived brightness. It also provides resistance to dust particles and shows a better image in general.

These devices are the perfect choice for a wide variety of applications, including POS systems, control panels in industrial fields, kiosk systems, office/residence automation, digital signage and in areas like shopping malls, classrooms, hotels and many more.

  • Anti-glare surface treatment (chemical etching)
  • 10-Finger-Multi Touch Capacitive Touch Panel
  • 1.1mm cover glass with 7H surface hardness
  • Optically bonded Touch Panel to LCD Panel
  • Patented IP65 front with silicone seal
  • Integrated audio speakers (2x2w)
  • 2 year guarantee (24/7 operation)

Request a Quote
SKU: 13.3″ Capacitive Touch Monitor Categories: , , Brand:

Description

Product Details

Model number FT133TMCAPOB
Global article code 3030516087
European article code 4010077705
EAN number 6920734013104

IP Rating

IP 65 front / IP40 back

LCD Panel

Screen diagonal 13.3″ / 33.7 cm
Display active screen size 29.38 cm x 16.52 cm (11.56 in x 6.503 in)
Aspect ratio 16:9
Physical resolution 1920×1080 px
Maximum showable resolution 1920×1080 px
Brightness 300 (cd/m²)
Contrast 800:1
Typical reaction time Tr/ Tf 14/11 (ms)
Visual angle horizontal/vertical 170/170 (°)
Backlight LED
Backlight lifetime 15,000 (hours)

Touch Panel

Touch technology Projected Capacitive 10-point Multitouch
Available touch panel drivers Windows
Linux
Mac
Android
Touch lifetime Unlimited
Surface hardness 7H
Surface treatment Anti-glare (chemical etching)
Glass strengthening Chemically Strengthened

Operation/Mechanical

Operating temperature -10 °C ~ +60 °C (14 °F ~ 140 °F)
Humidity range 10% – 90% RH
Net weight 3.30 kg / 7.2752 lb
Gross weight (incl. cartonage) 5.20 kg / 11.464 lb
Housing material Rubber front, aluminum back case
Housing sizes 338.2 mm x 220.7 mm x 42.3 mm (13.31 in x 8.688 in x 1.665 in)
Clamp support Yes
cut-out for clamp supports (L X H) 322.0 mm x 196.0 mm (12.67 in x 7.716 in)
Amount of clamps required 4
Mounting VESA 100

Power

Power indicator Green LED
Power supply 100-240V ACDC active switching; 12V DC-Out
Working power 12 V
Power consumption 8 W
Standby power 1 W

External Connectors

Video 1x HDMI 1.3 (incl. HDCP)
1x VGA
1x DP
Audio 1x PC-Audio
Touch Connectors 1x USB-B
Other Connectors 1x 12V DC-In (screwable) 1x Serial port (for controller)

Included in the delivery

Power Supply (see Power section)
Short Installation Manual
USB-Touch Cable

Downloads

Acrobat Reader for PDFs Download from external page
3D model Download 3D model (PDF)
Datasheet Download Datasheet (PDF)
Manual Download manual (PDF)
Short-Manual Download Short-Manual (PDF)
Capacitive touch drivers (w/o Linux) Download CTD (RAR) | Online Rar to ZIP
Capacitive touch drivers Linux Download CTDL (deb)
