Description
Product Details
Model number | FT07TMB |
Global article code | 20205005878 |
European article code | 1010500166 |
EAN number | 6920734007110 |
IP Rating
IP 40 |
LCD Panel
Screen diagonal | 7″ / 17.7 cm |
Display active screen size | 15.36 cm x 9.00 cm (6.047 in x 3.543 in) |
Aspect ratio | 16:9 |
Physical resolution | 1024×600 px |
Maximum showable resolution | 1920×1080 px |
Brightness | 500 (cd/m²) |
Contrast | 700:1 |
Typical reaction time Tr/ Tf | 10/15 (ms) |
Visual angle horizontal/vertical | 150/145 (°) |
Backlight | LED |
Backlight lifetime | 20000 (hours) |
Touch Panel
Touch technology | 4-Wire Resistive |
Available touch panel drivers | Windows Linux Mac Android |
Touch lifetime | 1 million touch in 1 location |
Surface hardness | 3H |
Surface treatment | Anti-glare |
Operation/Mechanical
Operating temperature | -25 °C ~ +75 °C (-13 °F ~ 167 °F) |
Humidity range | 10% – 90% RH |
Net weight | 0.60 kg / 1.3227 lb |
Gross weight (incl. cartonage) | 1.80 kg / 3.9683 lb |
Housing material | Plastic |
Housing sizes | 179.0 mm x 123.0 mm x 32.0 mm (7.047 in x 4.842 in x 1.259 in) |
Power
Power indicator | Green LED |
Power supply | 100-240V ACDC active switching; 12V DC-Out |
Working power | 8-36 V |
Power consumption | 7 W |
Standby power | 1 W |
External Connectors
Video | 1x HDMI 1.3 (incl. HDCP) 1x VGA 1x Video1 1x Video2_Backview 1x Backview-Detect 1x YpbPr |
Audio | 1x VGA-Audio, 1x Video-Audio, 1x Ear-Out |
Touch Connectors | 1x USB 1x Serial |
Other Connectors | 1x 8~36V DC-In 1x USB (front) |
Included in the delivery
Power Supply (see Power section) Short Installation Manual Stylus Remote Controller Cables – VGA, USB Touch Car Adapter AV Molex 2.5 Connector faytech FTV75PSF Stand Mounting Frame Mounting Rail Cable Cover |
