Innoaiot
Industrial Panel PC
Products Overview
The PPC-series is a low-power, cost-effective Industrial Panel PC, which is equipped with an industrial-grade LED display and an IP65 rated true flat touch screen. It is used in industrial automation control operations, manufacturing execution systems(MES), workflow monitoring
Industrial Panel PC
PPC-J015SAR
Product features：Industrial-grade 15" XGA LCD panel with 50k backlight lifetimeHigh precision 5-wires resistive touch, EETI controllerIP65 grade aluminum alloy front panelIntel® Celeron® J1900 quad-core 2.0 GHz processor1 x DDR3 SDRAM, max.8GB, 1 x mSATA / 1 x 2.5" SATA SSD2 x Intel® 211 1GbE Ethernet, support WoL and PXE2 x RS232/422/485, RS485 support automatic flow controlSupport TPM2.0 hardware securitySupports embedded / VESA 100mm x 100mm mounting holes9V to 36V DC Wide Range Power Input，Supporting OVP / OCP / RPP
PPC-J015SRC
Product features：Industrial-grade 15" XGA LCD panel with 50k backlight lifetimeTrue-flat touchscreen with multi-touch projected capacitive controlIP66 grade aluminum alloy front panelIntel® Celeron® J1900 quad-core 2.0 GHz processor1 x DDR3 SDRAM, max.8GB, 1 x mSATA / 1 x 2.5" SATA SSD2 x Intel® 211 1GbE Ethernet, support WoL and PXE2 x RS232/422/485, RS485 support automatic flow controlSupport TPM2.0 hardware securitySupports 19 inch Rack mount / VESA 100mm x 100mm mounting holes9V to 36V DC Wide Range Power Input，Supporting OVP / OCP / RPP
PPC-J024WCC
Product features：Industrial-grade 23.8" FHD LCD panel with 30k backlight lifetimeTrue-flat touchscreen with multi-touch projected capacitive controlIP66 grade stainless steel SUS304 front panelIntel® Celeron® J1900 quad-core 2.0 GHz processor1 x DDR3 SDRAM, max.8GB, 1 x mSATA / 1 x 2.5" SATA SSD2 x Intel® 211 1GbE Ethernet, support WoL and PXE2 x RS232/422/485, RS485 support automatic flow controlSupport TPM2.0 hardware securitySupports embedded / VESA 100mm x 100mm mounting holes9V to 36V DC Wide Range Power Input，Supporting OVP / OCP / RPP
PPC-J133WAC
Product features：Industrial-grade 13.3" FHD LCD panel with 50k backlight lifetimeTrue-flat touchscreen with multi-touch projected capacitive controlIP66 grade aluminum alloy front panelIntel® Celeron® J1900 quad-core 2.0 GHz processor1 x DDR3 SDRAM, max.8GB, 1 x mSATA / 1 x 2.5" SATA SSD2 x Intel® 211 1GbE Ethernet, support WoL and PXE2 x RS232/422/485, RS485 support automatic flow controlSupport TPM2.0 hardware securitySupports embedded / VESA 100mm x 100mm mounting holes9V to 36V DC Wide Range Power Input，Supporting OVP / OCP / RPP
PPC-J133WBC
Product features：Industrial-grade 13.3" FHD LCD panel with 50k backlight lifetimeTrue-flat touchscreen with multi-touch projected capacitive controlIP66 grade aluminum alloy front panelIntel® Celeron® J1900 quad-core 2.0 GHz processor1 x DDR3 SDRAM, max.8GB, 1 x mSATA / 1 x 2.5" SATA SSD2 x Intel® 211 1GbE Ethernet, support WoL and PXE2 x RS232/422/485, RS485 support automatic flow controlSupport TPM2.0 hardware securitySupports embedded / VESA 100mm x 100mm mounting holes9V to 36V DC Wide Range Power Input，Supporting OVP / OCP / RPP
PPC-J156WAC
Product features：Industrial-grade 15.6" FHD LCD panel with 50k backlight lifetimeTrue-flat touchscreen with multi-touch projected capacitive controlIP66 grade aluminum alloy front panelIntel® Celeron® J1900 quad-core 2.0 GHz processor1 x DDR3 SDRAM, max.8GB, 1 x mSATA / 1 x 2.5" SATA SSD2 x Intel® 211 1GbE Ethernet, support WoL and PXE2 x RS232/422/485, RS485 support automatic flow controlSupport TPM2.0 hardware securitySupports embedded / VESA 100mm x 100mm mounting holes9V to 36V DC Wide Range Power Input，Supporting OVP / OCP / RPP
PPC-J156WAR
Product features：Industrial-grade 15.6" FHD LCD panel with 50k backlight lifetimeHigh precision 5-wires resistive touch, EETI controllerIP65 grade aluminum alloy front panelIntel® Celeron® J1900 quad-core 2.0 GHz processor1 x DDR3 SDRAM, max.8GB, 1 x mSATA / 1 x 2.5" SATA SSD2 x Intel® 211 1GbE Ethernet, support WoL and PXE2 x RS232/422/485, RS485 support automatic flow controlSupport TPM2.0 hardware securitySupports embedded / VESA 100mm x 100mm mounting holes9V to 36V DC Wide Range Power Input，Supporting OVP / OCP / RPP
