27″ Capacitive Touch PC (N4200)

faytech’s Capacitive PC series stands out among competition with its fanless silent operation, IP65 front panel design, high reliability and fine craftwork. It is the perfect choice for industrial and business application. It has flat edge to edge glass with IP65 water- and dust proof front panels and a sturdy aluminum case with stable VESA 100 fixation bolts.

The touch PC is powered by faytech’s industrial Apollo Lake mainboard. It is driven by the powerful Intel® Pentium® N4200 QuadCore processor with up to 2.50 GHz clock frequency. This version is equipped with 4GByte RAM, 128G SSD and Intel’s HD Graphic chipset, supporting FullHD, DirectX 11.1 and OpenGL 4.0.

These faytech PCs are the perfect choice for a wide variety of applications including POS systems, control panels in industrial fields, in kiosk systems, office/residence automation, digital signage and in areas like shopping malls, classrooms, hotels and many more.

  • Intel® Pentium® N4200 QuadCore CPU
  • 4GB RAM memory, 128GB Industrial SSD
  • Supports Windows 10 & Linux (32Bit, 64Bit)
  • Anti-glare surface treatment (chemical etching)
  • 10-Finger-Multi Touch Capacitive Touch Panel
  • 1.1mm cover glass with 7H surface hardness
  • Optically bonded Touch Panel to LCD Panel
  • Patented IP65 front with silicon seal
  • Integrated W-LAN
  • 2 year guarantee (24/7 usage)

Request a Quote
SKU: 27″ Capacitive Touch PC (N4200) Categories: , , Brand:


Product Details

Model number FT27N4200CAPOB
Global article code 3030510215
European article code 1010502387
EAN number 6920734002702

IP Rating

IP 65 front / IP40 back

PC System

CPU Intel® Pentium® QuadCore N4200
GPU Graphics Intel® HD Graphics
Audio Realtek ALC3251 Audio CODEC
Memory 4GB DDR3L non-ECC (max. 8GB)
Switchable Storage faytech Industrial 128GB SSD
Network 2x Realtek PCIe GB LAN 8111G (1x optional with POE); W-LAN
Driver Support Windows 10 + Linux Ubuntu
Preinstalled OS Linux Ubuntu

LCD Panel

Screen diagonal 27″ / 68.5 cm
Display active screen size 59.76 cm x 33.62 cm (23.52 in x 13.23 in)
Aspect ratio 16:9
Physical resolution 1920×1080 px
Maximum showable resolution 1920×1200 px
Brightness 300 (cd/m²)
Contrast 3000:1
Typical reaction time Tr/ Tf 7/5 (ms)
Visual angle horizontal/vertical 178/178 (°)
Backlight LED
Backlight lifetime 30,000 (hours)

Touch Panel

Touch technology Projected Capacitive 10-point Multitouch
Touch lifetime Unlimited
Surface hardness 7H
Surface treatment Anti-glare (chemical etching)
Glass strengthening Chemically Strengthened


Operating temperature -10 °C ~ +60 °C (14 °F ~ 140 °F)
Humidity range 10% – 90% RH
Net weight 8.00 kg / 17.636 lb
Gross weight (incl. cartonage) 10.50 kg / 23.148 lb
Housing material Rubber frame, Aluminum IPC back case
Housing sizes 663.0 mm x 405.0 mm x 62.0 mm (26.10 in x 15.94 in x 2.440 in)
Clamp support Yes
cut-out for clamp supports (L X H) 639.0 mm x 381.0 mm (25.15 in x 15.00 in)
Amount of clamps required 10
Mounting VESA 100


Power indicator Green LED
Power supply 100-240V ACDC active switching; 12V DC-Out
Working power 12 V
Power consumption 42 W
Standby power 1 W

Internal Connectors

1x SO-DIMM, max. 8GB, DDR3L 1333/1600/1867 non-ECC, Single channel memory
3x RS232/RS485 COM connectors switchable in BIOS
2x LCD Backlight control/LCD panel voltage box
1x 5V/12V SATA power connector
1x 12V DC power connector (2-pin)
1x 4-pin SATA power connector
1x S/PDIF output pin header
1x 8-bit Digital I/O interface
1x Line-out / Mic-in header
1x Front Panel box header
1x Serial ATA 6Gb/s
1x MIPI CSI connector
1x LVDS box header
2x USB 3.0 box header

External Connectors

1x 12V DC-In (screwable)
1x W-LAN antenna connector (RP-SMA male)
2x USB 2.0
2x USB 3.0
1x DP
1x MIC-In & EAR-Out
1x 10-PIN DIO as RJ50
2x COM port Full-PIN – RS232/485; 5V/12V
2x COM port 3-PIN – RX, TX, GND; RS232/485; 5V/12V
2x 10/100/1000Mbit RJ45 Ports
1x 2.5″ module slot, changeable SSD included

Expansion Slots

1x mSATA full size (occupied by SSD)
1x M.2 E-Key Slot (occupied by Wifi card)
1x SATA connector
1x External PCIe x1 Straddle connector

Included in the delivery

Power Supply (see Power section)
Short Installation Manual
Standard Stand
W-LAN antenna (RP-SMA female)


Acrobat Reader for PDFs Download from external page
3D model Download 3D model (PDF)
Datasheet Download Datasheet (PDF)
Manual Download manual (PDF)
Short-Manual Download Short-Manual (PDF)
Capacitive touch drivers (w/o Linux) Download CTD (RAR) | Online Rar to ZIP
Capacitive touch drivers Linux Download CTDL (deb)
WiFi driver Download WiFi (RAR) | Online Rar to ZIP
Apollo Lake Mainboard Drivers (Windows) Download ALMD-WIN (RAR) | Online Rar to ZIP
