Description
Product Details
| Model number | FT156V40MIRROR |
| Global article code | 3030501648 |
| European article code | 1010501560 |
| EAN number | 6920734016815 |
IP Rating
| IP 65 |
LCD Panel
| Screen diagonal | 15.6″ / 39.6 cm |
| Display active screen size | 34.42 cm x 19.36 cm (13.55 in x 7.622 in) |
| Aspect ratio | 16:9 |
| Physical resolution | 1920×1080 px |
| Maximum showable resolution | 1920×1080 px |
| Brightness | 1000 (cd/m²) |
| Contrast | 800:1 |
| Typical reaction time Tr/ Tf | 15/15 (ms) |
| Visual angle horizontal/vertical | 170/170 (°) |
| Backlight | LED |
| Backlight lifetime | 30000 (hours) |
Touch Panel
| Touch technology | Projected Capacitive 10-point Multitouch with mirror effect |
| Touch lifetime | Unlimited |
| Surface hardness | 7H |
Operation/Mechanical
| Operating temperature | -10 °C ~ +60 °C (14 °F ~ 140 °F) |
| Humidity range | 10% – 90% RH |
| Net weight | 5.65 kg / 12.456 lb |
| Gross weight (incl. cartonage) | 8.00 kg / 17.636 lb |
| Housing material | Mirrored Front, Aluminum Housing |
| Housing sizes | 660.0 mm x 505.0 mm x 18.5 mm (25.98 in x 19.88 in x 0.728 in) |
Power
| Power supply | 100-240V ACDC active switching; 12V DC-Out |
| Working power | 8-18 V |
| Power consumption | 15 W |
| Standby power | 1 W |
External Connectors
| Video | |
| Audio | |
| Touch Connectors | |
| Other Connectors | 1x 12V DC-In (screwable) |
Included in the delivery
| Power Supply (see Power section) Short Installation Manual |
IP Rating
| IP 65 |
PC System
| CPU | Allwinner® V40 QuadCore |
| Chipset | Cortex A7 |
| GPU Graphics | ARM® Mali400 Mp2 Complies with OpenGL ES 2.0/1.1 |
| Audio | |
| Memory | 1GB DDR3 |
| Storage | 8GB EMMC Flash |
| Network | 10M/100M/1000M Network; W-LAN |
| Driver Support | Android 6.0 / 4.4 |
| Preinstalled OS | Android 6.0 / 4.4 |
LCD Panel
| Screen diagonal | 15.6″ / 39.6 cm |
| Display active screen size | 34.42 cm x 19.36 cm (13.55 in x 7.622 in) |
| Aspect ratio | 16:9 |
| Physical resolution | 1920×1080 px |
| Maximum showable resolution | 1920×1080 px |
| Brightness | 1000 (cd/m²) |
| Contrast | 800:1 |
| Typical reaction time Tr/ Tf | 15/15 (ms) |
| Visual angle horizontal/vertical | 170/170 (°) |
| Backlight | LED |
| Backlight lifetime | 30000 (hours) |
Touch Panel
| Touch technology | Projected Capacitive 10-point Multitouch with mirror effect |
| Touch lifetime | Unlimited |
| Surface hardness | 7H |
Operation/Mechanical
| Operating temperature | -10 °C ~ +60 °C (14 °F ~ 140 °F) |
| Humidity range | 10% – 90% RH |
| Net weight | 5.65 kg / 12.456 lb |
| Gross weight (incl. cartonage) | 8.00 kg / 17.636 lb |
| Housing material | Mirrored Front, Aluminum Housing |
| Housing sizes | 660.0 mm x 505.0 mm x 18.5 mm (25.98 in x 19.88 in x 0.728 in) |
Power
| Power supply | 100-240V ACDC active switching; 12V DC-Out |
| Working power | 8-18 V |
| Power consumption | 15 W |
| Standby power | 1 W |
Internal Connectors
External Connectors
| 1x 8-18V DC-In (screwable) |
Expansion Slots
Included in the delivery
| Power Supply (see Power section) Short Installation Manual |
